UPLC Columns

USHD UPLC Columns

The selection sheet lists USHD reversed-phase, HILIC, normal-phase, phenyl, PFP, and SEC columns for UPLC / UHPLC. Tables below follow that sheet: phase, particle size, pore size, and catalog number.

1.7 μm is only 1.0 mm ID. 1.8 μm and 2.5 μm are the other sub-2 μm sizes. 3 μm, 3.5 μm, and 5 μm are listed on the same sheet. Most pores are 120 Å. C18-Pro and C8-Pro are 150 Å. ZIL 5 μm is 100 Å. The bio columns include 300 Å.

Product Details

Request Quote

UPLC columns

Column Overview

The video already on this page.

What is HPLC Column ? Check This Video You Will Know

Features

One selection sheet for the UPLC / UHPLC columns: reversed phase, HILIC, normal phase, phenyl, PFP, and SEC.

1.7 μm on 1.0 mm1.8 μm and 2.5 μm3 μm and 3.5 μm5 μm120 Å, 150 Å, 300 Å100 Å ZIL 5 μm

1.0 mm ID is its own group — Ten columns, all 1.7 μm and 120 Å, all 1.0×50 mm or 1.0×100 mm. Phases are C18, C18-AQ, C18-AR, C18-T, and C8.
Sub-2 μm analytical hardware — 1.8 μm, and 2.5 μm on HILIC-Amide and HILIC-ZIL. Inner diameters are 2.1 mm, 3.0 mm, and 4.6 mm. The longest 1.8 μm column on the sheet is 4.6×100 mm.
3 μm, 3.5 μm, and 5 μm — Same phases, larger particles. 3.5 μm appears only on C18-Pro and C8-Pro, both 150 Å. 5 μm is the only particle size for SiO2, CN, and NH2.
SEC at the end of the sheet — SEC-Bio in 4.6×300 and 7.8×300 mm, then C8-Bio and C4-Bio at 5 μm, 300 Å.

Return to top

Product Selection

333 catalog rows, in sheet order. Pick the pressure class first, then the phase.

1.7 μm

1.0 mm ID, 120 Å

10 columns, C18 family and C8
View 1.7 μm →

1.8 μm and 2.5 μm

2.1, 3.0, and 4.6 mm

69 columns, including HILIC 2.5 μm
View tables →

3 μm and 3.5 μm

Higher efficiency, lower pressure than 1.8 μm

116 columns. 3.5 μm is C18-Pro and C8-Pro only
View tables →

5 μm

Routine UHPLC and HPLC hardware

138 columns, including SiO2, CN, NH2, and the bio phases
View tables →

Polar analytes

HILIC

SiO2, Amide, and ZIL. ZIL 5 μm is 100 Å
View HILIC →

Biomolecules

SEC and bio phases

SEC-Bio, C8-Bio, C4-Bio
View SEC →

Return to top

Specifications

Every catalog number below is on the UPLC selection sheet. Particle size and pore size are the values printed beside that block.

USHD C18-Pro

USP L1. 150 Å, 5 μm and 3.5 μm. Published carbon load 10%, pH 2–8. Shorter retention than the 120 Å C18 phases.

USHD C18-Pro, 5 μm, 150 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00338	2.1×50 mm	5 μm	150 Å
P1F0B-00366	2.1×100 mm	5 μm	150 Å
P1F0B-00367	3.0×50 mm	5 μm	150 Å
P1F0B-00368	3.0×100 mm	5 μm	150 Å
P1F0B-00806	3.0×150 mm	5 μm	150 Å
P1F0B-00355	4.6×50 mm	5 μm	150 Å
P1F0B-00347	4.6×100 mm	5 μm	150 Å
P1F0B-00276	4.6×150 mm	5 μm	150 Å
P1F0B-00337	4.6×250 mm	5 μm	150 Å

USHD C18-Pro, 3.5 μm, 150 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00356	2.1×50 mm	3.5 μm	150 Å
P1F0B-00357	2.1×100 mm	3.5 μm	150 Å
P1F0B-00363	3.0×50 mm	3.5 μm	150 Å
P1F0B-00280	3.0×100 mm	3.5 μm	150 Å
P1F0B-00279	3.0×150 mm	3.5 μm	150 Å
P1F0B-00364	4.6×50 mm	3.5 μm	150 Å
P1F0B-00365	4.6×100 mm	3.5 μm	150 Å
P1F0B-00278	4.6×150 mm	3.5 μm	150 Å
P1F0B-00277	4.6×250 mm	3.5 μm	150 Å

USHD C18

USP L1. 120 Å. 5 μm, 3 μm, and 1.8 μm, plus 1.7 μm on 1.0 mm ID. Published carbon load 17%, pH 2–8.

USHD C18, 5 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00378	2.1×50 mm	5 μm	120 Å
P1F0B-00379	2.1×100 mm	5 μm	120 Å
P1F0B-00381	3.0×50 mm	5 μm	120 Å
P1F0B-00380	3.0×100 mm	5 μm	120 Å
P1F0B-00382	3.0×150 mm	5 μm	120 Å
P1F0B-00383	4.6×50 mm	5 μm	120 Å
P1F0B-00384	4.6×100 mm	5 μm	120 Å
P1F0B-00290	4.6×150 mm	5 μm	120 Å
P1F0B-00289	4.6×250 mm	5 μm	120 Å

USHD C18, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00374	2.1×50 mm	3 μm	120 Å
P1F0B-00336	2.1×100 mm	3 μm	120 Å
P1F0B-00738	2.1×150 mm	3 μm	120 Å
P1F0B-00375	3.0×50 mm	3 μm	120 Å
P1F0B-00294	3.0×100 mm	3 μm	120 Å
P1F0B-00293	3.0×150 mm	3 μm	120 Å
P1F0B-00376	4.6×50 mm	3 μm	120 Å
P1F0B-00292	4.6×100 mm	3 μm	120 Å
P1F0B-00291	4.6×150 mm	3 μm	120 Å

USHD C18, 1.7 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00657	1.0×50 mm	1.7 μm	120 Å
P1F0B-00659	1.0×100 mm	1.7 μm	120 Å

USHD C18, 1.8 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00297	2.1×50 mm	1.8 μm	120 Å
P1F0B-00274	2.1×100 mm	1.8 μm	120 Å
P1F0B-00739	2.1×150 mm	1.8 μm	120 Å
P1F0B-00369	3.0×50 mm	1.8 μm	120 Å
P1F0B-00295	3.0×100 mm	1.8 μm	120 Å
P1F0B-00346	3.0×150 mm	1.8 μm	120 Å
P1F0B-00370	4.6×50 mm	1.8 μm	120 Å
P1F0B-00371	4.6×100 mm	1.8 μm	120 Å

ValuSil C18

USP L1, 120 Å, 16.4% carbon, 328 m²/g, fully end-capped. This sheet lists the two 5 μm sizes. The wider ValuSil set is on the ValuSil page.

ValuSil C18, 5 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00903	4.6×150 mm	5 μm	120 Å
P1F0B-00904	4.6×250 mm	5 μm	120 Å

USHD C18-AQ

USP L1. 120 Å, 12% carbon, pH 2–8. For polar compounds and high-water or 100% aqueous mobile phases.

USHD C18-AQ, 5 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00396	2.1×50 mm	5 μm	120 Å
P1F0B-00397	2.1×100 mm	5 μm	120 Å
P1F0B-00398	3.0×50 mm	5 μm	120 Å
P1F0B-00399	3.0×100 mm	5 μm	120 Å
P1F0B-00724	3.0×150 mm	5 μm	120 Å
P1F0B-00400	4.6×50 mm	5 μm	120 Å
P1F0B-00401	4.6×100 mm	5 μm	120 Å
P1F0B-00282	4.6×150 mm	5 μm	120 Å
P1F0B-00281	4.6×250 mm	5 μm	120 Å

USHD C18-AQ, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00391	2.1×50 mm	3 μm	120 Å
P1F0B-00392	2.1×100 mm	3 μm	120 Å
P1F0B-00741	2.1×150 mm	3 μm	120 Å
P1F0B-00393	3.0×50 mm	3 μm	120 Å
P1F0B-00286	3.0×100 mm	3 μm	120 Å
P1F0B-00285	3.0×150 mm	3 μm	120 Å
P1F0B-00394	4.6×50 mm	3 μm	120 Å
P1F0B-00284	4.6×100 mm	3 μm	120 Å
P1F0B-00283	4.6×150 mm	3 μm	120 Å

USHD C18-AQ, 1.7 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00663	1.0×50 mm	1.7 μm	120 Å
P1F0B-00665	1.0×100 mm	1.7 μm	120 Å

USHD C18-AQ, 1.8 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00288	2.1×50 mm	1.8 μm	120 Å
P1F0B-00287	2.1×100 mm	1.8 μm	120 Å
P1F0B-00740	2.1×150 mm	1.8 μm	120 Å
P1F0B-00385	3.0×50 mm	1.8 μm	120 Å
P1F0B-00386	3.0×100 mm	1.8 μm	120 Å
P1F0B-00653	3.0×150 mm	1.8 μm	120 Å
P1F0B-00387	4.6×50 mm	1.8 μm	120 Å
P1F0B-00388	4.6×100 mm	1.8 μm	120 Å

USHD C18-AR

USP L1. 120 Å, 10% carbon, pH 0.5–8. For low-pH methods.

USHD C18-AR, 5 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00415	2.1×50 mm	5 μm	120 Å
P1F0B-00416	2.1×100 mm	5 μm	120 Å
P1F0B-00417	3.0×50 mm	5 μm	120 Å
P1F0B-00418	3.0×100 mm	5 μm	120 Å
P1F0B-00419	4.6×50 mm	5 μm	120 Å
P1F0B-00420	4.6×100 mm	5 μm	120 Å
P1F0B-00309	4.6×150 mm	5 μm	120 Å
P1F0B-00308	4.6×250 mm	5 μm	120 Å

USHD C18-AR, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00410	2.1×50 mm	3 μm	120 Å
P1F0B-00411	2.1×100 mm	3 μm	120 Å
P1F0B-00742	2.1×150 mm	3 μm	120 Å
P1F0B-00412	3.0×50 mm	3 μm	120 Å
P1F0B-00313	3.0×100 mm	3 μm	120 Å
P1F0B-00312	3.0×150 mm	3 μm	120 Å
P1F0B-00413	4.6×50 mm	3 μm	120 Å
P1F0B-00311	4.6×100 mm	3 μm	120 Å
P1F0B-00310	4.6×150 mm	3 μm	120 Å

USHD C18-AR, 1.7 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00672	1.0×50 mm	1.7 μm	120 Å
P1F0B-00670	1.0×100 mm	1.7 μm	120 Å

USHD C18-AR, 1.8 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00315	2.1×50 mm	1.8 μm	120 Å
P1F0B-00314	2.1×100 mm	1.8 μm	120 Å
P1F0B-00743	2.1×150 mm	1.8 μm	120 Å
P1F0B-00402	3.0×50 mm	1.8 μm	120 Å
P1F0B-00403	3.0×100 mm	1.8 μm	120 Å
P1F0B-00744	3.0×150 mm	1.8 μm	120 Å
P1F0B-00406	4.6×50 mm	1.8 μm	120 Å
P1F0B-00407	4.6×100 mm	1.8 μm	120 Å

USHD C18-T

USP L1. 120 Å, 14% carbon, pH 1–11, on hybrid silica. For wide-pH and alkaline conditions.

USHD C18-T, 5 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00456	2.1×50 mm	5 μm	120 Å
P1F0B-00457	2.1×100 mm	5 μm	120 Å
P1F0B-00458	3.0×50 mm	5 μm	120 Å
P1F0B-00459	3.0×100 mm	5 μm	120 Å
P1F0B-00460	4.6×50 mm	5 μm	120 Å
P1F0B-00461	4.6×100 mm	5 μm	120 Å
P1F0B-00299	4.6×150 mm	5 μm	120 Å
P1F0B-00298	4.6×250 mm	5 μm	120 Å

USHD C18-T, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00451	2.1×50 mm	3 μm	120 Å
P1F0B-00452	2.1×100 mm	3 μm	120 Å
P1F0B-00745	2.1×150 mm	3 μm	120 Å
P1F0B-00453	3.0×50 mm	3 μm	120 Å
P1F0B-00303	3.0×100 mm	3 μm	120 Å
P1F0B-00302	3.0×150 mm	3 μm	120 Å
P1F0B-00454	4.6×50 mm	3 μm	120 Å
P1F0B-00301	4.6×100 mm	3 μm	120 Å
P1F0B-00300	4.6×150 mm	3 μm	120 Å

USHD C18-T, 1.7 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00675	1.0×50 mm	1.7 μm	120 Å
P1F0B-00677	1.0×100 mm	1.7 μm	120 Å

USHD C18-T, 1.8 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00305	2.1×50 mm	1.8 μm	120 Å
P1F0B-00304	2.1×100 mm	1.8 μm	120 Å
P1F0B-00746	2.1×150 mm	1.8 μm	120 Å
P1F0B-00445	3.0×50 mm	1.8 μm	120 Å
P1F0B-00446	3.0×100 mm	1.8 μm	120 Å
P1F0B-00747	3.0×150 mm	1.8 μm	120 Å
P1F0B-00448	4.6×50 mm	1.8 μm	120 Å
P1F0B-00447	4.6×100 mm	1.8 μm	120 Å

USHD C30

C30 reversed phase, 120 Å, 5 μm and 3 μm. A longer alkyl chain than C18, for the sizes on this sheet.

USHD C30, 5 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00644	2.1×50 mm	5 μm	120 Å
P1F0B-00645	2.1×100 mm	5 μm	120 Å
P1F0B-00646	3.0×50 mm	5 μm	120 Å
P1F0B-00647	3.0×100 mm	5 μm	120 Å
P1F0B-00648	4.6×50 mm	5 μm	120 Å
P1F0B-00649	4.6×100 mm	5 μm	120 Å
P1F0B-00650	4.6×150 mm	5 μm	120 Å
P1F0B-00565	4.6×250 mm	5 μm	120 Å

USHD C30, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00807	2.1×50 mm	3 μm	120 Å
P1F0B-00716	2.1×100 mm	3 μm	120 Å
P1F0B-00808	2.1×150 mm	3 μm	120 Å
P1F0B-00809	3.0×50 mm	3 μm	120 Å
P1F0B-00810	3.0×100 mm	3 μm	120 Å
P1F0B-00717	3.0×150 mm	3 μm	120 Å
P1F0B-00811	4.6×50 mm	3 μm	120 Å
P1F0B-00812	4.6×100 mm	3 μm	120 Å
P1F0B-00732	4.6×150 mm	3 μm	120 Å

USHD C8-Pro

150 Å, 5 μm and 3.5 μm. The sheet does not list a 1.8 μm or 120 Å C8-Pro.

USHD C8-Pro, 5 μm, 150 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00469	2.1×50 mm	5 μm	150 Å
P1F0B-00470	2.1×100 mm	5 μm	150 Å
P1F0B-00471	3.0×50 mm	5 μm	150 Å
P1F0B-00472	3.0×100 mm	5 μm	150 Å
P1F0B-00473	4.6×50 mm	5 μm	150 Å
P1F0B-00474	4.6×100 mm	5 μm	150 Å
P1F0B-00349	4.6×150 mm	5 μm	150 Å
P1F0B-00348	4.6×250 mm	5 μm	150 Å

USHD C8-Pro, 3.5 μm, 150 Å

7 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00339	2.1×50 mm	3.5 μm	150 Å
P1F0B-00462	2.1×100 mm	3.5 μm	150 Å
P1F0B-00463	3.0×50 mm	3.5 μm	150 Å
P1F0B-00464	3.0×100 mm	3.5 μm	150 Å
P1F0B-00465	4.6×50 mm	3.5 μm	150 Å
P1F0B-00466	4.6×100 mm	3.5 μm	150 Å
P1F0B-00467	4.6×150 mm	3.5 μm	150 Å

USHD C8

USP L7. 120 Å. 5 μm, 3 μm, 1.8 μm, and 1.7 μm on 1.0 mm ID.

USHD C8, 5 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00524	2.1×50 mm	5 μm	120 Å
P1F0B-00525	2.1×100 mm	5 μm	120 Å
P1F0B-00526	3.0×50 mm	5 μm	120 Å
P1F0B-00527	3.0×100 mm	5 μm	120 Å
P1F0B-00813	3.0×150 mm	5 μm	120 Å
P1F0B-00528	4.6×50 mm	5 μm	120 Å
P1F0B-00529	4.6×100 mm	5 μm	120 Å
P1F0B-00354	4.6×150 mm	5 μm	120 Å
P1F0B-00332	4.6×250 mm	5 μm	120 Å

USHD C8, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00516	2.1×50 mm	3 μm	120 Å
P1F0B-00517	2.1×100 mm	3 μm	120 Å
P1F0B-00748	2.1×150 mm	3 μm	120 Å
P1F0B-00518	3.0×50 mm	3 μm	120 Å
P1F0B-00519	3.0×100 mm	3 μm	120 Å
P1F0B-00749	3.0×150 mm	3 μm	120 Å
P1F0B-00520	4.6×50 mm	3 μm	120 Å
P1F0B-00521	4.6×100 mm	3 μm	120 Å
P1F0B-00522	4.6×150 mm	3 μm	120 Å

USHD C8, 1.7 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00684	1.0×50 mm	1.7 μm	120 Å
P1F0B-00682	1.0×100 mm	1.7 μm	120 Å

USHD C8, 1.8 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00475	2.1×50 mm	1.8 μm	120 Å
P1F0B-00509	2.1×100 mm	1.8 μm	120 Å
P1F0B-00750	2.1×150 mm	1.8 μm	120 Å
P1F0B-00510	3.0×50 mm	1.8 μm	120 Å
P1F0B-00511	3.0×100 mm	1.8 μm	120 Å
P1F0B-00751	3.0×150 mm	1.8 μm	120 Å
P1F0B-00512	4.6×50 mm	1.8 μm	120 Å
P1F0B-00563	4.6×100 mm	1.8 μm	120 Å

USHD C4

Shorter alkyl chain than C8, 120 Å, 5 μm and 3 μm.

USHD C4, 5 μm, 120 Å

10 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00633	2.1×50 mm	5 μm	120 Å
P1F0B-00634	2.1×100 mm	5 μm	120 Å
P1F0B-00752	2.1×150 mm	5 μm	120 Å
P1F0B-00635	3.0×50 mm	5 μm	120 Å
P1F0B-00636	3.0×100 mm	5 μm	120 Å
P1F0B-00753	3.0×150 mm	5 μm	120 Å
P1F0B-00630	4.6×50 mm	5 μm	120 Å
P1F0B-00631	4.6×100 mm	5 μm	120 Å
P1F0B-00632	4.6×150 mm	5 μm	120 Å
P1F0B-00345	4.6×250 mm	5 μm	120 Å

USHD C4, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00637	2.1×50 mm	3 μm	120 Å
P1F0B-00638	2.1×100 mm	3 μm	120 Å
P1F0B-00754	2.1×150 mm	3 μm	120 Å
P1F0B-00639	3.0×50 mm	3 μm	120 Å
P1F0B-00640	3.0×100 mm	3 μm	120 Å
P1F0B-00755	3.0×150 mm	3 μm	120 Å
P1F0B-00641	4.6×50 mm	3 μm	120 Å
P1F0B-00642	4.6×100 mm	3 μm	120 Å
P1F0B-00643	4.6×150 mm	3 μm	120 Å

USHD NH2

Amino phase, 5 μm, 120 Å. Used for sugars and as a normal-phase alternative.

USHD NH2, 5 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00701	2.1×50 mm	5 μm	120 Å
P1F0B-00702	2.1×100 mm	5 μm	120 Å
P1F0B-00703	3.0×50 mm	5 μm	120 Å
P1F0B-00704	3.0×100 mm	5 μm	120 Å
P1F0B-00705	4.6×50 mm	5 μm	120 Å
P1F0B-00706	4.6×100 mm	5 μm	120 Å
P1F0B-00559	4.6×150 mm	5 μm	120 Å
P1F0B-00344	4.6×250 mm	5 μm	120 Å

USHD Phenyl

Phenyl phase, 120 Å, 5 μm, 3 μm, and 1.8 μm. Extra aromatic selectivity versus C18.

USHD Phenyl, 5 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00543	2.1×50 mm	5 μm	120 Å
P1F0B-00544	2.1×100 mm	5 μm	120 Å
P1F0B-00545	3.0×50 mm	5 μm	120 Å
P1F0B-00546	3.0×100 mm	5 μm	120 Å
P1F0B-00547	4.6×50 mm	5 μm	120 Å
P1F0B-00548	4.6×100 mm	5 μm	120 Å
P1F0B-00317	4.6×150 mm	5 μm	120 Å
P1F0B-00316	4.6×250 mm	5 μm	120 Å

USHD Phenyl, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00538	2.1×50 mm	3 μm	120 Å
P1F0B-00539	2.1×100 mm	3 μm	120 Å
P1F0B-00759	2.1×150 mm	3 μm	120 Å
P1F0B-00540	3.0×50 mm	3 μm	120 Å
P1F0B-00321	3.0×100 mm	3 μm	120 Å
P1F0B-00320	3.0×150 mm	3 μm	120 Å
P1F0B-00541	4.6×50 mm	3 μm	120 Å
P1F0B-00319	4.6×100 mm	3 μm	120 Å
P1F0B-00318	4.6×150 mm	3 μm	120 Å

USHD Phenyl, 1.8 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00323	2.1×50 mm	1.8 μm	120 Å
P1F0B-00322	2.1×100 mm	1.8 μm	120 Å
P1F0B-00760	2.1×150 mm	1.8 μm	120 Å
P1F0B-00532	3.0×50 mm	1.8 μm	120 Å
P1F0B-00533	3.0×100 mm	1.8 μm	120 Å
P1F0B-00761	3.0×150 mm	1.8 μm	120 Å
P1F0B-00534	4.6×50 mm	1.8 μm	120 Å
P1F0B-00535	4.6×100 mm	1.8 μm	120 Å

USHD PFP

Pentafluorophenyl, USP L43, 120 Å, 5 μm and 3 μm. The same standard sizes as the PFP column page.

USHD PFP, 5 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00553	2.1×50 mm	5 μm	120 Å
P1F0B-00554	2.1×100 mm	5 μm	120 Å
P1F0B-00555	3.0×50 mm	5 μm	120 Å
P1F0B-00556	3.0×100 mm	5 μm	120 Å
P1F0B-00557	4.6×50 mm	5 μm	120 Å
P1F0B-00558	4.6×100 mm	5 μm	120 Å
P1F0B-00325	4.6×150 mm	5 μm	120 Å
P1F0B-00324	4.6×250 mm	5 μm	120 Å

USHD PFP, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00549	2.1×50 mm	3 μm	120 Å
P1F0B-00550	2.1×100 mm	3 μm	120 Å
P1F0B-00762	2.1×150 mm	3 μm	120 Å
P1F0B-00334	3.0×50 mm	3 μm	120 Å
P1F0B-00329	3.0×100 mm	3 μm	120 Å
P1F0B-00328	3.0×150 mm	3 μm	120 Å
P1F0B-00551	4.6×50 mm	3 μm	120 Å
P1F0B-00327	4.6×100 mm	3 μm	120 Å
P1F0B-00326	4.6×150 mm	3 μm	120 Å

USHD SiO2

Bare silica, USP L3, 5 μm, 120 Å. Same six sizes as the normal-phase page.

USHD SiO2, 5 μm, 120 Å

6 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00503	3.0×50 mm	5 μm	120 Å
P1F0B-00504	3.0×100 mm	5 μm	120 Å
P1F0B-00505	4.6×50 mm	5 μm	120 Å
P1F0B-00506	4.6×100 mm	5 μm	120 Å
P1F0B-00507	4.6×150 mm	5 μm	120 Å
P1F0B-00508	4.6×250 mm	5 μm	120 Å

USHD CN

Cyanopropyl, USP L10, 5 μm, 120 Å. Usable in normal and reversed phase.

USHD CN, 5 μm, 120 Å

6 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00498	3.0×50 mm	5 μm	120 Å
P1F0B-00499	3.0×100 mm	5 μm	120 Å
P1F0B-00500	4.6×50 mm	5 μm	120 Å
P1F0B-00501	4.6×100 mm	5 μm	120 Å
P1F0B-00502	4.6×150 mm	5 μm	120 Å
P1F0B-00331	4.6×250 mm	5 μm	120 Å

USHD HILIC-SiO2

Bare-silica HILIC, 120 Å, 5 μm, 3 μm, and 1.8 μm.

USHD HILIC-SiO2, 5 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00437	2.1×50 mm	5 μm	120 Å
P1F0B-00438	2.1×100 mm	5 μm	120 Å
P1F0B-00439	3.0×50 mm	5 μm	120 Å
P1F0B-00440	3.0×100 mm	5 μm	120 Å
P1F0B-00441	4.6×50 mm	5 μm	120 Å
P1F0B-00442	4.6×100 mm	5 μm	120 Å
P1F0B-00443	4.6×150 mm	5 μm	120 Å
P1F0B-00444	4.6×250 mm	5 μm	120 Å

USHD HILIC-SiO2, 3 μm, 120 Å

9 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00429	2.1×50 mm	3 μm	120 Å
P1F0B-00430	2.1×100 mm	3 μm	120 Å
P1F0B-00763	2.1×150 mm	3 μm	120 Å
P1F0B-00431	3.0×50 mm	3 μm	120 Å
P1F0B-00432	3.0×100 mm	3 μm	120 Å
P1F0B-00764	3.0×150 mm	3 μm	120 Å
P1F0B-00433	4.6×50 mm	3 μm	120 Å
P1F0B-00434	4.6×100 mm	3 μm	120 Å
P1F0B-00435	4.6×150 mm	3 μm	120 Å

USHD HILIC-SiO2, 1.8 μm, 120 Å

8 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00421	2.1×50 mm	1.8 μm	120 Å
P1F0B-00422	2.1×100 mm	1.8 μm	120 Å
P1F0B-00765	2.1×150 mm	1.8 μm	120 Å
P1F0B-00423	3.0×50 mm	1.8 μm	120 Å
P1F0B-00424	3.0×100 mm	1.8 μm	120 Å
P1F0B-00766	3.0×150 mm	1.8 μm	120 Å
P1F0B-00425	4.6×50 mm	1.8 μm	120 Å
P1F0B-00426	4.6×100 mm	1.8 μm	120 Å

USHD HILIC-Amide

Amide HILIC, 120 Å. 5 μm, 3 μm, 2.5 μm, and 1.8 μm. The 2.5 μm pair is 2.1×50 and 2.1×100 mm.

USHD HILIC-Amide, 5 μm, 120 Å

3 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00814	3.0×150 mm	5 μm	120 Å
P1F0B-00342	4.6×150 mm	5 μm	120 Å
P1F0B-00405	4.6×250 mm	5 μm	120 Å

USHD HILIC-Amide, 3 μm, 120 Å

4 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00798	2.1×150 mm	3 μm	120 Å
P1F0B-00815	3.0×100 mm	3 μm	120 Å
P1F0B-00566	3.0×150 mm	3 μm	120 Å
P1F0B-00567	4.6×150 mm	3 μm	120 Å

USHD HILIC-Amide, 2.5 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00817	2.1×50 mm	2.5 μm	120 Å
P1F0B-00818	2.1×100 mm	2.5 μm	120 Å

USHD HILIC-Amide, 1.8 μm, 120 Å

5 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00819	2.1×50 mm	1.8 μm	120 Å
P1F0B-00731	2.1×100 mm	1.8 μm	120 Å
P1F0B-00820	2.1×150 mm	1.8 μm	120 Å
P1F0B-00821	3.0×100 mm	1.8 μm	120 Å
P1F0B-00822	3.0×150 mm	1.8 μm	120 Å

USHD HILIC-ZIL

ZIL HILIC. The 5 μm sizes are 100 Å. The 3 μm, 2.5 μm, and 1.8 μm sizes are 120 Å.

USHD HILIC-ZIL, 5 μm, 100 Å

3 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00823	3.0×150 mm	5 μm	100 Å
P1F0B-00343	4.6×150 mm	5 μm	100 Å
P1F0B-00404	4.6×250 mm	5 μm	100 Å

USHD HILIC-ZIL, 3 μm, 120 Å

4 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00824	2.1×150 mm	3 μm	120 Å
P1F0B-00825	3.0×100 mm	3 μm	120 Å
P1F0B-00816	3.0×150 mm	3 μm	120 Å
P1F0B-00826	4.6×150 mm	3 μm	120 Å

USHD HILIC-ZIL, 2.5 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00827	2.1×100 mm	2.5 μm	120 Å
P1F0B-00828	4.6×150 mm	2.5 μm	120 Å

USHD HILIC-ZIL, 1.8 μm, 120 Å

4 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00799	2.1×100 mm	1.8 μm	120 Å
P1F0B-00801	2.1×150 mm	1.8 μm	120 Å
P1F0B-00829	3.0×100 mm	1.8 μm	120 Å
P1F0B-00830	3.0×150 mm	1.8 μm	120 Å

USHD SEC-Bio

Size-exclusion for biomolecules. 5 μm at 120 Å and 300 Å, and 3 μm at 300 Å. 4.6×300 and 7.8×300 mm.

USHD SEC-Bio, 5 μm, 120 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00487	4.6×300 mm	5 μm	120 Å
P1F0B-00307	7.8×300 mm	5 μm	120 Å

USHD SEC-Bio, 5 μm, 300 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00489	4.6×300 mm	5 μm	300 Å
P1F0B-00340	7.8×300 mm	5 μm	300 Å

USHD SEC-Bio, 3 μm, 300 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00484	4.6×300 mm	3 μm	300 Å
P1F0B-00485	7.8×300 mm	3 μm	300 Å

USHD C8-Bio

USP L7 biomolecule phase. This sheet lists 5 μm, 300 Å, 4.6×150 and 4.6×250 mm.

USHD C8-Bio, 5 μm, 300 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00478	4.6×150 mm	5 μm	300 Å
P1F0B-00479	4.6×250 mm	5 μm	300 Å

USHD C4-Bio

USP L26 biomolecule phase. This sheet lists 5 μm, 300 Å, 4.6×150 and 4.6×250 mm.

USHD C4-Bio, 5 μm, 300 Å

2 sizes.

Catalog No.	Dimension	Particle size	Pore size
P1F0B-00476	4.6×150 mm	5 μm	300 Å
P1F0B-00477	4.6×250 mm	5 μm	300 Å

Request Quote Ask Method Support

Related: C18 HPLC columns · ValuSil C18 · C8 HPLC columns · Phenyl · PFP · HILIC · Normal phase · SEC.

Return to top

Applications

Uses already described for these phases on the current column pages.

Small-molecule reversed phase

C18, C18-AQ, C18-AR, C18-T, C8, and C30 for pharmaceutical, food, and environmental methods. AQ when the mobile phase is mostly water. AR at low pH. T when the method goes alkaline.

Selectivity other than C18

Phenyl for aromatic compounds. PFP for aromatics, halogenated compounds, and basic analytes. CN when the method can run normal or reversed phase.

Polar and biomolecule work

HILIC-SiO2, HILIC-Amide, and HILIC-ZIL for polar metabolites. NH2 for sugars. SEC-Bio, C8-Bio, and C4-Bio for larger biomolecules.

Return to top

Support

Send the catalog number if you have it. Otherwise send phase, particle size, and dimensions.

1.7 μm versus 1.8 μm

1.7 μm is the 1.0 mm ID pair. 1.8 μm starts at 2.1 mm ID. They are not interchangeable hardware.

Phase confirmation

C18-Pro and C8-Pro are the 150 Å phases. The other reversed-phase blocks on this sheet are 120 Å, except the 300 Å bio columns and the 100 Å ZIL 5 μm block.

Custom sizes

Dimensions that are not in the tables can be requested as a custom packed column.

Return to top

FAQ

How the sheet is organized, and where it differs from the older UPLC cards.

01How is this UPLC list split?

The sheet is one 超高压色谱柱 list. It is grouped here by phase, then by particle size. 1.7 μm is only the 1.0×50 mm and 1.0×100 mm columns. 1.8 μm and 2.5 μm are the other sub-2 μm sizes, on 2.1 mm, 3.0 mm, and 4.6 mm hardware. 3 μm, 3.5 μm, and 5 μm are the larger-particle columns on the same sheet. SEC-Bio also has 7.8×300 mm.

02What is the 1.7 μm column?

USHD C18, C18-AQ, C18-AR, C18-T, and C8 each list two 1.7 μm, 120 Å columns: 1.0×50 mm and 1.0×100 mm. No other inner diameter is printed at 1.7 μm.

03Which pore sizes are on the sheet?

Most phases are 120 Å. C18-Pro and C8-Pro are 150 Å. HILIC-ZIL 5 μm is 100 Å. SEC-Bio is 120 Å or 300 Å. C8-Bio and C4-Bio on this sheet are 300 Å. The 5 μm SEC-Bio pair is one 120 Å set and one 300 Å set.

04Where is ValuSil C18?

This sheet lists ValuSil C18, 5 μm, 120 Å, as P1F0B-00903 (4.6×150 mm) and P1F0B-00904 (4.6×250 mm). The ValuSil product page has the wider 1.8 μm and 3 μm set.

05Are the PFP, SiO2, and CN numbers the same as the other pages?

Yes. USHD PFP 5 μm and 3 μm, USHD SiO2 5 μm, and USHD CN 5 μm match the catalog numbers already published on those product pages. On this sheet, HILIC-Amide 2.5 μm, 2.1×50 mm is P1F0B-00817, and P1F0B-00819 is HILIC-Amide 1.8 μm, 2.1×50 mm. The HILIC column page also lists 00819 as 2.5 μm, 2.1×50 mm. Confirm that pair before ordering.

06What did the old UPLC cards claim that this sheet does not?

The previous cards mixed 150 Å into C18 and C8, and listed 1.8 μm on phases where this sheet has no 1.8 μm row. C8-Pro on the sheet is 5 μm and 3.5 μm at 150 Å. Those older card lines are not in the catalog tables.

Return to top

Need a UPLC column matched to the method?

Request a USHD UPLC Quote

Send the catalog number, or the phase, particle size, and dimensions. We will confirm availability and pricing.

Helpful to include:

Catalog number, if it is in the table
Phase and particle size (1.7, 1.8, 2.5, 3, 3.5, or 5 μm)
Dimensions and pore size
Quantity and destination

Prefer email? [email protected] · Contact Us

UHPLCS Technical Inquiry

Inquiry Type

Full Name

Work Email

Company

Country / Region

Phone

Product, Sample or Project

Requirements / Current Challenge
